TP LINK TL-R480T LOAD BALANCE ROUTER
- AVAILABILITY:
- SKU: 8089
- CATEGORY: NETWORK ACCESSORIES
Up to 4 WAN ports equipped with advanced load balance to guarantee maximum bandwidth and backup capabilities
Provides extensive client account and network management for administrators with supported PPPoE Server
Marshals bandwidth resource to specific clients based on their unique application environments
2 YEAR WARRANTY
WAN Ports: 1 fixed WAN port and 3 changeable WAN/LAN ports (for a total of up to 4 WAN ports)
LAN Ports: 4 LAN ports
Load Balancing: Supports multiple load balancing strategies, including round robin, weighted round robin, and failover
QoS: Supports quality of service (QoS) to prioritize traffic
Security: Supports firewall, IP/MAC/URL/WEB filtering, and DoS attack prevention
Other Features: Supports PPPoE, PPTP, L2TP, and VPN pass-through
| HARDWARE FEATURES | |
|---|---|
| Standards and Protocols | IEEE 802.3, 802.3u, 802.3x, TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DDNS |
| Interface | 1 Fixed Ethernet WAN Port 1 Fixed Ethernet LAN Port 3 Changeable Ethernet WAN/LAN Ports |
| Network Media | 10BASE-T: UTP category 3, 4, 5 cable (Max 100m) 100BASE-TX: UTP category 5, 5e cable (Max 100m) |
| Button | Reset Button |
| Power Supply | Internal Universal Power Supply AC100-240V~50/60Hz input |
| Flash | 8MB |
| DRAM | 64MB |
| LED | PWR, SYS, WAN, LAN, WAN/LAN |
| Dimensions ( W x D x H ) | 11.6*7.1*1.7in. (294*180*44mm) 13-inch Standard Rack-Mount Width, 1U Height |
| PERFORMANCE | |
|---|---|
| Concurrent Session | 30000 |
| BASIC FUNCTIONS | |
|---|---|
| WAN Connection Type | Static/Dynamic IP, PPPoE, PPTP, L2TP, Dual Access, Bigpond Cable |
| DHCP | DHCP Server/Client, DHCP Address Reservation |
| MAC Clone | Modify WAN/LAN MAC Address |
| Switch Setting | Port Mirror, Rate Control, Port Configuration, Port VLAN |
| ADVANCED FUNCTIONS | |
|---|---|
| ACL | IP/MAC/URL/WEB Filtering |
| IGMP | IGMP Proxy/IGMP Snooping |
| Forwarding | Virtual Server, Port Triggering, DMZ |
| Load Balance | Policy Routing, Link Backup |
| NAT | One-to-One NAT, Multi-Nets NAT |
| Routing | Static Routing |
| Security | FTP/SIP/PPTP/IPsec/H.323 ALG, DoS Defence, Ping of Death |
| Traffic Control | Bandwidth Control, Session Limit |
| MANAGEMENT | |
|---|---|
| Service | PPPoE Server, E-Bulletin, Dynamic DNS, UPnP, App Control |
| Maintenance | Time Setting, Daylight Saving Time, SNMP, Diagnostics, Firmware Upgrade, Factory Defaults/Reboot, Backup/Restore, System Log, Remote Management, Statistics |
| OTHERS | |
|---|---|
| Certification | CE, FCC, RoHS |
| Package Contents | TL-R480T+ Power Cord RJ-45 Ethernet Cable Installation Guide Resource CD |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
