HIKVISION DS-3E0508D-O 8 PORT SWITCH
- AVAILABILITY:
- SKU: 8189
- CATEGORY: NETWORK ACCESSORIES,SWITCHES
The HIKVISION DS-3E0508D-O 8 Port Switch is a compact and reliable 8-port Gigabit unmanaged Ethernet switch designed for high-speed network connectivity in homes, offices, and small business environments. Featuring 8 × 10/100/1000 Mbps RJ45 ports, it delivers stable, high-speed data transmission for PCs, IP cameras, NVRs, printers, and other network devices. With plug-and-play operation, auto MDI/MDIX support, store-and-forward switching, and MAC address auto-learning, it ensures easy installation and dependable performance. Its compact design, low power consumption, and support for desktop or wall-mounted installation make the DS-3E0508D-O an ideal solution for expanding wired network connections.
2 YEAR WARRANTY
🌐 8 × Gigabit RJ45 Ports – Provides 10/100/1000 Mbps Ethernet connectivity for high-speed networking.
⚡ Gigabit Network Performance – Ideal for fast file transfers, IP cameras, NVRs, PCs, printers, and office networks.
🔄 Unmanaged Plug-and-Play Design – No configuration required for quick and easy installation.
🚀 16 Gbps Switching Capacity – Ensures smooth and efficient data transmission across connected devices.
🔀 Auto MDI/MDIX Support – Automatically detects cable types, eliminating the need for crossover cables.
📡 Store-and-Forward Switching – Delivers stable and reliable network communication with error checking.
🧠 Automatic MAC Address Learning – Learns and manages connected devices for efficient network operation.
🖥️ Desktop & Wall-Mount Design – Compact design allows flexible installation in various environments.
🧱 Compact ABS Housing – Lightweight yet durable construction for long-lasting performance.
⚡ 2kV Surge Protection – Helps protect the switch from electrical surges for improved reliability.
🏢 Ideal for Home & Business Networks – Suitable for offices, retail stores, classrooms, CCTV systems, and small business environments.
🛡️ Trusted Hikvision Quality – Reliable networking solution from Hikvision.
| Brand | Hikvision |
| Model | DS-3E0508D-O |
| Product Type | Unmanaged Gigabit Ethernet Switch |
| Switch Type | Layer 2 Unmanaged |
| Total Ports | 8 × 10/100/1000 Mbps RJ45 Ports |
| Port Speed | Gigabit Ethernet (10/100/1000 Mbps) |
| PoE Support | No |
| Switching Capacity | 16 Gbps |
| Packet Forwarding Rate | 11.90 Mpps |
| MAC Address Table | 4K |
| Internal Cache | 1.5 Mbits |
| Forwarding Mode | Store-and-Forward |
| Port Features | Auto MDI/MDIX, Auto-Negotiation |
| Flow Control | IEEE 802.3x Full Duplex Flow Control |
| Installation | Desktop / Wall Mount |
| Housing Material | ABS Plastic |
| Cooling | Fanless Design |
| Power Supply | 5V DC, 1A |
| Maximum Power Consumption | ≤5W |
| Surge Protection | 2KV |
| Operating Temperature | 0°C to +40°C |
| Storage Temperature | -40°C to +85°C |
| Operating Humidity | 5%–95% (Non-Condensing) |
| Dimensions | 124 × 25 × 61 mm |
| Weight | Approx. 93g |
| Applications | Home Networks, Offices, CCTV Systems, Schools, Small Business Networks |
