PROCESSOR CORE I5 6GEN
- AVAILABILITY:
- SKU: 1452
- CATEGORY: PC ACCESSORIES,PROCESSORS,USED PROCESSORS
Rs. 10,850.00Rs. 10,200.00
- Cores/Threads: 4 cores / 4 threads (some models may have Hyper-Threading)
- Base Clock Speed: 2.3 GHz to 3.3 GHz (varies by specific model)
- Turbo Boost: Up to 3.9 GHz (depending on the model)
- Architecture: 14nm process technology
- Cache: 6MB Intel Smart Cache
- Integrated Graphics: Intel HD Graphics 530 (up to 1.1 GHz)
- TDP: 35W to 95W (varies by model)
- Socket Type: LGA 1151
3 MONTH WARRANTY
Cores/Threads: 4 cores / 4 threads (some models may have Hyper-Threading)
Base Clock Speed: 2.3 GHz to 3.3 GHz (varies by specific model)
Turbo Boost: Up to 3.9 GHz (depending on the model)
Architecture: 14nm process technology
Cache: 6MB Intel Smart Cache
Integrated Graphics: Intel HD Graphics 530 (up to 1.1 GHz)
TDP: 35W to 95W (varies by model)
Socket Type: LGA 1151
CPU Specifications
Total Cores
4
Total Threads
4
Max Turbo Frequency
3.60 GHz
Intel® Turbo Boost Technology 2.0 Frequency
3.60 GHz
Processor Base Frequency
3.20 GHz
Cache
6 MB Intel® Smart Cache
Bus Speed
8 GT/s
TDP
65 W
Memory Specifications
Max Memory Size (dependent on memory type)
64 GB
Memory Types
DDR4-1866/2133, DDR3L-1333/1600 @ 1.35V
Max # of Memory Channels
2
Max Memory Bandwidth
34.1 GB/s
ECC Memory Supported
No
GPU Specifications
GPU Name
Intel® HD Graphics 530
Graphics Base Frequency
350 MHz
Graphics Max Dynamic Frequency
1.05 GHz
Graphics Video Max Memory
64 GB
Graphics Output
eDP/DP/HDMI/DVI
4K Support
Yes, at 60Hz
Max Resolution (HDMI)
4096x2304@24Hz
Max Resolution (DP)‡
4096x2304@60Hz
Max Resolution (eDP - Integrated Flat Panel)‡
4096x2304@60Hz
Max Resolution (VGA)‡
N/A
DirectX* Support
12
OpenGL* Support
4.5
Intel® Quick Sync Video
Yes
Intel® InTru™ 3D Technology
Yes
Intel® Clear Video HD Technology
Yes
Intel® Clear Video Technology
Yes
# of Displays Supported
3
Device ID
0x1912
Expansion Options
Scalability
1S Only
PCI Express Revision
3.0
PCI Express Configurations ‡
Up to 1x16, 2x8, 1x8+2x4
Max # of PCI Express Lanes
16
Package Specifications
Sockets Supported
FCLGA1151
Max CPU Configuration
1
Thermal Solution Specification
PCG 2015C (65W)
TCASE
71°C
Package Size
37.5mm x 37.5mm
Advanced Technologies
Intel® Optane™ Memory Supported
No
Intel® Turbo Boost Technology
2.0
Intel® Hyper-Threading Technology
No
Intel® Transactional Synchronization Extensions
Yes
Intel® 64
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2
Idle States
Yes
Enhanced Intel SpeedStep® Technology
Yes
Thermal Monitoring Technologies
Yes
Intel® Identity Protection Technology
Yes
Security & Reliability
Intel vPro® Eligibility
Intel vPro® Platform
Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® ME
Intel® AES New Instructions
Yes
Secure Key
Yes
Intel® Memory Protection Extensions (Intel® MPX)
Yes
Intel® OS Guard
Yes
Intel® Trusted Execution Technology
Yes
Execute Disable Bit
Yes
Intel® Boot Guard
Yes
Intel® Stable IT Platform Program (SIPP)
Yes
Intel® Virtualization Technology (VT-x)
Yes
Intel® Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
