POWER UNIT 500W 24 PIN - BLACK
- AVAILABILITY:
- SKU: 3004
- CATEGORY: PC ACCESSORIES,POWER SUPPLY
Rs. 3,000.00Rs. 2,700.00
Connectors:
- 20+4 Pin Main Connectors x 1
- 4-Pin 12V Connectors x 1
- SATA Connectors x 3
- 4-Pin Molex Connectors x 2
- Floppy Drive Connectors x 1
3 MONTH WARRANTY
Support - Compliant with latest Intel standards ATX 12V, V2.0
Efficiency > 70%
MTBF > 50000hrs
Cooling System - 120mm sleeve bearing fan
Protection - Over Voltage Protection (OVP), Under Voltage, Over Power Protection (OPP), Over Temperature Protection (OTP) & Short Circuit Protection (SCP)
| Dimensions: | 150mm x 86mm x 142mm (W x H x D) |
| Input Voltage: | 230 VAC |
| Input Current: | 5A |
| Input Frequency Range: | 50-60Hz |
| PFC: | Passive PFC |
| Power Good Signal: | 100-500 ms |
| Hold Up Time: | >17ms |
| Efficiency: | >70% |
| MTBF: | 50,000 Hours |
| Protection: | OVP / OTP / OCP/ OLP/ OPP/ SCP |
| Power: | 500W |
| Operation Temperature: | 0-40°C (Nominal Input Voltage) |
| Safety: | CE / FCC / UL / TUV |
| Cooling: | 12cm Fan |
| Noise: | < 23 dBA |
