INTEL CORE I7 14700 PROCESSOR BX8071514700
- AVAILABILITY:
- SKU: 0001920
- CATEGORY: PC ACCESSORIES,PROCESSORS
- Brand: INTEL
- Part Number: BX8071514700
- Processor Series: Intel Core i7CPU
- Socket Type: LGA 1700
3 YEAR WARRANTY
Cores/Threads: 8 cores, 16 threads
Base Clock: 2.6 GHz
Max Turbo Boost Clock: Up to 5.3 GHz
Cache: 24 MB Intel Smart Cache
TDP (Thermal Design Power): 125W
Socket: LGA 1700
Architecture: Raptor Lake (14nm process)
Integrated Graphics: Intel UHD Graphics 770 (up to 1.65 GHz)
Product Collection | Intel® Core™ i7 Processors (14th gen) | |
Code Name | Products formerly Raptor Lake | |
Vertical Segment | Desktop | |
Processor Number | i7-14700 | |
Lithography | Intel 7 | |
Use Conditions | PC/Client/Tablet, Workstation | |
CPU Specifications | ||
Total Cores | 20 | |
# of Performance-cores | 8 | |
# of Efficient-cores | 12 | |
Total Threads | 28 | |
Max Turbo Frequency | 5.4 GHz | |
Intel® Turbo Boost Max Technology 3.0 Frequency ‡ | 5.4 GHz | |
Performance-core Max Turbo Frequency | 5.3 GHz | |
Efficient-core Max Turbo Frequency | 4.2 GHz | |
Performance-core Base Frequency | 2.1 GHz | |
Efficient-core Base Frequency | 1.5 GHz | |
Cache | 33 MB Intel® Smart Cache | |
Total L2 Cache | 28 MB | |
Processor Base Power | 65 W | |
Maximum Turbo Power | 219 W | |
Memory Specifications | ||
Max Memory Size (dependent on memory type) | 192 GB | |
Memory Types | Up to DDR5 5600 MT/s | |
Up to DDR4 3200 MT/s | ||
Max # of Memory Channels | 2 | |
Max Memory Bandwidth | 89.6 GB/s | |
ECC Memory Supported ‡ | Yes | |
GPU Specifications | ||
GPU Name‡ | Intel® UHD Graphics 770 | |
Graphics Base Frequency | 300 GHz | |
Graphics Max Dynamic Frequency | 1.6 GHz | |
Graphics Output | eDP 1.4b, DP 1.4a, HDMI 2.1 | |
Execution Units | 32 | |
Max Resolution (HDMI)‡ | 4096 x 2160 @ 60Hz | |
Max Resolution (DP)‡ | 7680 x 4320 @ 60Hz | |
Max Resolution (eDP - Integrated Flat Panel)‡ | 5120 x 3200 @ 120Hz | |
DirectX* Support | 12 | |
OpenGL* Support | 4.5 | |
OpenCL* Support | 3 | |
Multi-Format Codec Engines | 2 | |
Intel® Quick Sync Video | Yes | |
Intel® Clear Video HD Technology | Yes | |
# of Displays Supported ‡ | 4 | |
Device ID | 0xA780 | |
Expansion Options | ||
Direct Media Interface (DMI) Revision | 4 | |
Max # of DMI Lanes | 8 | |
Scalability | 1S Only | |
PCI Express Revision | 5.0 and 4.0 | |
PCI Express Configurations ‡ | Up to 1x16+4, 2x8+4 | |
Max # of PCI Express Lanes | 20 | |
Package Specifications | ||
Sockets Supported | FCLGA1700 | |
Max CPU Configuration | 1 | |
Thermal Solution Specification | PCG 2020C | |
TJUNCTION | 100°C | |
Package Size | 45.0 mm x 37.5 mm | |
Advanced Technologies | ||
Intel® Gaussian & Neural Accelerator | 3 | |
Intel® Thread Director | Yes | |
Intel® Deep Learning Boost (Intel® DL Boost) on CPU | Yes | |
Intel® Speed Shift Technology | Yes | |
Intel® Turbo Boost Max Technology 3.0 ‡ | Yes | |
Intel® Turbo Boost Technology ‡ | 2 | |
Intel® Hyper-Threading Technology ‡ | Yes | |
Intel® 64 ‡ | Yes | |
Instruction Set | 64-bit | |
Instruction Set Extensions | Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2 | |
Idle States | Yes | |
Enhanced Intel SpeedStep® Technology | Yes | |
Thermal Monitoring Technologies | Yes | |
Intel® Volume Management Device (VMD) | Yes | |
Security & Reliability | ||
Intel® Standard Manageability (ISM) ‡ | Yes | |
Intel® Control-Flow Enforcement Technology | Yes | |
Intel® AES New Instructions | Yes | |
Secure Key | Yes | |
Intel® OS Guard | Yes | |
Execute Disable Bit ‡ | Yes | |
Intel® Boot Guard | Yes | |
Mode-based Execute Control (MBEC) | Yes | |
Intel® Virtualization Technology (VT-x) ‡ | Yes | |
Intel® Virtualization Technology for Directed I/O (VT-d) ‡ | Yes | |
Intel® VT-x with Extended Page Tables (EPT) ‡ | Yes |
