HIKVISION DS-7616NXI-K1 ACUSENSE 16 CHANNEL NVR
- SKU: 3904
- CATEGORY: CCTV CAMERS
The Hikvision DS-7616NXI-K1 AcuSense 16-Channel NVR is a reliable and intelligent network video recorder designed for efficient CCTV surveillance management. Supporting up to 16 network cameras, it provides centralized video recording, playback, and monitoring for security systems. Its AcuSense technology helps improve detection accuracy by focusing on relevant human and vehicle events, helping reduce unnecessary alarms. Ideal for homes, offices, shops, warehouses, and commercial properties, the DS-7616NXI-K1 provides a practical solution for managing modern IP camera surveillance systems.
2 YEARS WARRANTY
🎥 16-Channel IP NVR – Supports up to 16 IP camera inputs for centralized surveillance recording and management.
🧠 AcuSense Technology – Intelligent analytics help reduce false alarms and minimize manual monitoring effort.
👤 Human & Vehicle Detection – Helps distinguish people and vehicles from other moving objects for more accurate security alerts.
🚨 Motion Detection 2.0 – Provides intelligent motion analysis for improved event detection.
🛡️ Perimeter Protection – Supports human and vehicle recognition for perimeter-related events to help reduce false alarms.
🙂 Face Recognition – Supports face detection/recognition functions, including face-picture comparison and face search.
🔍 Smart Search – Quickly searches selected areas of recorded video to help find relevant events.
📹 Up to 12MP Decoding – Supports decoding of high-resolution camera streams, with up to 1-ch @ 12MP on the standard DS-7616NXI-K1 specification.
▶️ Smart Playback – Helps users efficiently review important sections of recorded footage.
⚡ 160Mbps Incoming Bandwidth – Handles high-volume IP camera video streams efficiently.
🎞️ H.265+ Compression – Efficient video compression can reduce storage requirements by up to 75% compared with traditional compression.
💾 1 SATA HDD Interface – Supports one hard drive with capacity up to 10TB on the standard model.
▶️ 16-Channel Synchronous Playback – Allows simultaneous playback of footage from all 16 channels.
🖥️ 4K HDMI Output – Provides HDMI output up to 4K resolution for high-quality monitoring.
🖥️ Independent HDMI & VGA Outputs – Supports flexible display connection through HDMI and VGA.
🌐 Gigabit Network Interface – Features a 10/100/1000Mbps self-adaptive Ethernet port for fast network connectivity.
📱 Hik-Connect Support – Enables convenient remote monitoring and network management through compatible Hikvision platforms.
🔐 TLS Stream Encryption – Helps secure video transmission over the network.
🔄 Multiple Video Formats – Supports H.265+, H.265, H.264+ and H.264 video compression formats.
🔊 Two-Way Audio Support – Supports two-way audio through compatible audio-enabled devices.
🏢 1U Compact Design – Compact recorder suitable for professional surveillance installations and equipment racks.
🏠 Wide Application – Suitable for homes, offices, shops, warehouses, factories, hotels and commercial CCTV systems.
| Brand | Hikvision |
| Model | DS-7616NXI-K1 |
| Product Type | Network Video Recorder (NVR) |
| Series | K-Series AcuSense |
| Channels | 16-Channel IP |
| IP Camera Inputs | Up to 16 Channels |
| Incoming Bandwidth | Up to 160 Mbps |
| Video Compression | H.265+ / H.265 / H.264+ / H.264 |
| Recording Resolution | Up to 12 MP |
| Decoding Capacity | Up to 1-ch @ 12MP / 2-ch @ 8MP / 4-ch @ 4MP / 8-ch @ 1080p |
| Synchronous Playback | 16 Channels |
| AcuSense | Yes |
| Motion Detection 2.0 | All Channels |
| Human & Vehicle Detection | Yes |
| Perimeter Protection | Yes |
| Facial Recognition | 1-ch facial recognition for video stream / 4-ch for face picture |
| Smart Search | Yes |
| Smart Playback | Yes |
| HDMI Output | 1 × HDMI, up to 4K |
| VGA Output | 1 × VGA |
| Video Output | Independent HDMI & VGA |
| Audio Input | 1 × RCA |
| Audio Output | 1 × RCA |
| Two-Way Audio | Supported |
| HDD Interface | 1 × SATA |
| Maximum HDD Capacity | Up to 10TB |
| Ethernet | 1 × RJ-45 Gigabit Ethernet |
| Network Speed | 10/100/1000 Mbps |
| USB | Front & Rear USB interfaces |
| Network Protocols | TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SMTP, SNMP, HTTP, HTTPS, ONVIF, etc. |
| Remote Connection | Up to 128 users/connections |
| Hik-Connect | Supported |
| H.265+ Storage Saving | Up to 75% storage reduction |
| Encryption | Stream over TLS |
| Rack Size | 1U |
| Power Supply | 12V DC |
| Power Consumption | ≤10W without HDD |
| Operating Temperature | -10°C to +55°C |
| Operating Humidity | 10%–90% |
| Dimensions | Approx. 385 × 315 × 52mm |
| Weight | Approx. 1.8kg without HDD |
