HIKVISION DS-7116HGHI-M1 DVR
- AVAILABILITY:
- SKU: 3192
- CATEGORY: CCTV ACCESSORIES,DVR
- Deep learning based human and vehicle targets classification of Motion Detection 2.0
- H.265 Pro+/H.265 Pro/H.265 video compression
- HDTVI/AHD/CVI/CVBS/IP video input
- Audio via coaxial cable
- Up to 18-ch IP camera input (up to 5 MP)
- Encoding ability up to 1080p lite @ 15 fps
- Max. 1200 m for 720p HDTVI signal
2 YEAR WARRANTY
Deep learning based human and vehicle targets classification of Motion Detection 2.0
H.265 Pro+/H.265 Pro/H.265 video compression
HDTVI/AHD/CVI/CVBS/IP video input
Audio via coaxial cable
Up to 18-ch IP camera input (up to 5 MP)
Encoding ability up to 1080p lite @ 15 fps
Max. 1200 m for 720p HDTVI signal
Motion Detection 2.0
Human/Vehicle Analysis | Deep learning-based motion detection 2.0 is enabled by default for all analog channels, it can classify human and vehicle, and extremely reduce false alarms caused by objects like leaves and lights
Quick search by object or event type is supported |
Video and Audio
IP Video Input | 2-ch (up to 18-ch) Up to 5 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
Analog Video Input | 16-ch BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
HDTVI Input | 1080p25, 1080p30, 720p25, 720p30 |
AHD Input | 1080p25, 1080p30, 720p25, 720p30 |
HDCVI Input | 1080p25, 1080p30, 720p25, 720p30 |
CVBS Input | PAL/NTSC |
HDMI Output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
VGA Output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
Video Output Mode | HDMI/VGA simultaneous output |
Audio Input | 1-ch RCA (2.0 Vp-p, 1 KΩ), and 16-ch via coaxial cable |
Audio Output | 1-ch, RCA (Linear, 1 KΩ) |
Two-Way Audio | 1-ch, RCA (2.0 Vp-p, 1 KΩ) (using the first audio input) |
Synchronous Playback | 16-ch |
Recording
Video Compression | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
Encoding Resolution | For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF For 720p stream access: 720p/WD1/4CIF/VGA/CIF For standard definition stream access: WD1/4CIF/VGA/CIF |
Frame Rate | Main stream: For 1080p stream access: 1080p Lite/720p Lite/WD1/4CIF/VGA/CIF@15 fps For 720p stream access: 720p/WD1/4CIF/VGA/CIF@15 fps
For SD stream access: WD1/4CIF/VGA/CIF@25 fps (P)/30 fps (N) |
Sub-stream: | For 1080p and 720p stream access CIF/QVGA@15 fps
For SD stream access: CIF/QVGA@25 fps (P)/30 fps (N) |
Video Bitrate | 32 Kbps to 4 Mbps |
Dual-stream | Support |
Stream Type | Video, Video & Audio |
Audio Compression | G.711u |
Audio Bitrate | 64 Kbps |
Network
Total Bandwidth | 96 Mbps |
Remote Connection | 128 |
Network Protocol | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, UPnP™, HTTPS, ONVIF |
Network Interface | 1, RJ45 10M/100M self-adaptive Ethernet interface |
Auxiliary Interface
SATA | 1, SATA interface |
Capacity | Up to 10 TB capacity for each disk |
USB Interface | 2 × USB 2.0 |
General
Power Supply | 12 VDC, 1.6 A |
Consumption | ≤ 7 W (without HDD) |
Working Temperature | -10 °C to 55 °C (14 °F to 131 °F) |
Working Humidity | 10% to 90% |
Dimension (W × D × H) | 285 × 210 × 45 mm (11.2 × 8.3 × 1.8 inch) |
Weight | ≤ 1.8 kg (without HDD, 4.0 lb.) |
