HIKVISION DS-2CE10DF8T-F 3.6MM CAMRA
- AVAILABILITY:
- SKU: 3120
- CATEGORY: CCTV ACCESSORIES,CCTV CAMERS,ANALOG,OUTDOOR
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging
- Clear imaging against strong back light due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Up to 20 m white light distance for bright night imaging
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
- Water and dust resistant (IP68)
2 YEAR WARRANTY
High quality imaging with 2 MP, 1920 × 1080 resolution
24/7 color imaging
Clear imaging against strong back light due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
2.8 mm, 3.6 mm, 6 mm fixed focal lens
Up to 20 m white light distance for bright night imaging
One port for four switchable signals (TVI/AHD/CVI/CVBS)
Water and dust resistant (IP68)
Camera
- Image Sensor2 MP CMOS
- Max. Resolution1920 (H) × 1080 (V)
- Min. Illumination0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light ON
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Day & Night24/7 Color Imaging
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
- Signal SystemPAL/NTSC
- Slow ShutterMax. 16 times
- Light AlarmSolid Light Alarm (White Light)
Lens
- Lens Type2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Focal Length & FOV
2.8 mm, horizontal FOV: 106°, vertical FOV: 56°, diagonal FOV: 129°
3.6 mm, horizontal FOV: 83°, vertical FOV: 44°, diagonal FOV: 100°
6 mm, horizontal FOV: 54°, vertical FOV: 30°, diagonal FOV: 64°
- Lens MountM12
Illuminator
- Supplement Light TypeWhite Light
- Supplement Light RangeUp to 20 m
- Smart Supplement LightYes
- Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
Image SettingsBrightness;Contrast;Mirror;Sharpness;Anti-Banding
Frame Rate
CVI: 1080p@25fps/30fps
AHD: 1080p@25fps/30fps
CVBS: PAL/NTSC
TVI: 1080p@25fps/30fps
- Day/Night ModeColor
- Wide Dynamic Range (WDR)≥130 dB
- Image EnhancementWDR;BLC;HLC;Global;HLS
- Privacy Mask4 programmable privacy masks
- Noise Reduction3D DNR/2D DNR
- White BalanceAuto
- White LightAuto/Off
- AGCYes
Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
Event
- Motion Detection4 programmable motion areas
General
- MaterialMetal
- Dimension161.1 mm × 70 mm × 70 mm (6.34″ × 2.76″ × 2.76″)
- Approx. 390 g (0.86 lb.)
- Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- CommunicationHIKVISION-C
- LanguageEnglish
- Power Supply
12 VDC ± 25%,
Approval
- ProtectionIP68
