HIKVISION DS-2CE10DF3T-PFS COLORVU CAMERA
- AVAILABILITY:
- SKU: 3700
- CATEGORY: CCTV CAMERS,ANALOG,OUTDOOR
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- Clear imaging against strong back light due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm fixed focal lens
- Up to 20 m white light distance for bright night imaging
- High quality audio with audio over coaxial cable, built-in mic
- One port for four switchable signals (TVI/AHD/CVI/CVBS) Water and dust resistant (IP67)
2 YEAR WARRANTY
High quality imaging with 2 MP, 1920 × 1080 resolution
24/7 color imaging with F1.0 aperture
Clear imaging against strong back light due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
2.8 mm, 3.6 mm fixed focal lens
Up to 20 m white light distance for bright night imaging
High quality audio with audio over coaxial cable, built-in mic
One port for four switchable signals (TVI/AHD/CVI/CVBS) Water and dust resistant (IP67)
Camera
Image Sensor2 MP CMOS
Max. Resolution1920 (H) × 1080 (V)
Min. Illumination0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night24/7 Color Imaging
Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
Signal SystemPAL/NTSC
Slow ShutterMax. 16 times
Light AlarmSolid Light Alarm (White Light)
Lens
Lens Type2.8 mm, 3.6 mm fixed focal lens
Focal Length & FOV
3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91°
2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116°
Image Parameters SwitchSTD/HIGH-SAT/HIGHLIGHT
Image SettingsBrightness;Contrast;Mirror;Defective Pixel Correction;Sharpness;Anti-Banding;Smart Light
- Frame Rate
- CVI: 1080p @ 25 fps/30 fps
- AHD: 1080p @ 25 fps/30 fps
- CVBS: PAL/NTSC
- TVI: 1080p @ 25 fps/30 fps
Day/Night ModeColor
Wide Dynamic Range (WDR)≥130 dB
Image EnhancementWDR;BLC;HLC;Global;HLS
Privacy Mask4 programmable privacy masks
Noise Reduction3D DNR/2D DNR
White BalanceAuto/Manual
White LightAuto/Off
AGCYes
Interface
Video OutputSwitchable TVI/AHD/CVI/CVBS
AudioBuilt-in mic
Event
Motion Detection4 programmable motion areas
General
Material: Plastic
Dimension161.1 mm × 70 mm × 70 mm (6.34″ × 2.76″ × 2.76″)
Approx. 223 g (0.49 lb.)
Operating Condition-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
Communication: HIKVISION-C
Language: English
Power Supply
12 VDC ± 25%,
ConsumptionMax. 3.0 W
White Light RangeUp to 20 m
Approval
ProtectionIP67
