HIK-VISION DS-2CE12DF3T-FS AUDIO CAMERA
- AVAILABILITY:
- SKU: 3380
- CATEGORY: CCTV CAMERS,ANALOG,OUTDOOR
- High quality imaging with 2 MP, 1920 × 1080 resolution
- 24/7 color imaging with F1.0 aperture
- Clear imaging against strong back light due to 130 dB true WDR technology
- 3D DNR technology delivers clean and sharp images
- 2.8 mm, 3.6 mm, 6 mm fixed focal lens
- Up to 40 m white light distance for bright night imaging
- One port for four switchable signals (TVI/AHD/CVI/CVBS)
- Water and dust resistant (IP67)
- High quality audio with audio over coaxial cable, built-in mic
2 YEAR WARRANTY
High quality imaging with 2 MP, 1920 × 1080 resolution
24/7 color imaging with F1.0 aperture
Clear imaging against strong back light due to 130 dB true WDR technology
3D DNR technology delivers clean and sharp images
2.8 mm, 3.6 mm, 6 mm fixed focal lens
Up to 40 m white light distance for bright night imaging
One port for four switchable signals (TVI/AHD/CVI/CVBS)
Water and dust resistant (IP67)
High quality audio with audio over coaxial cable, built-in mic
Camera
Image Sensor: 2 MP CMOS
Max. Resolution: 1920 (H) × 1080 (V)
Min. Illumination: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night: 24/7 Color Imaging
Angle Adjustment
Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
Signal System: PAL/NTSC
Lens
Lens Type: 2.8 mm, 3.6 mm and 6 mm fixed focal lens
Focal Length & FOV
- 2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116°
- 3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91°
- 6 mm, horizontal FOV: 51°, vertical FOV: 28°, diagonal FOV: 59°
Lens Mount: M12
Illuminator
Supplement Light Type: White Light
Supplement Light Range: Up to 40 m
Smart Supplement Light: Yes
Image Parameters Switch: STD/HIGH-SAT/HIGHLIGHT
Image Settings: Brightness; Contrast; Mirror; Sharpness; Anti-Banding; AGC
Frame Rate
- TVI: 1080P@30fps, 1080P@25fps
- AHD: 1080P@30fps, 1080P@25fps
- CVI: 1080P@30fps, 1080P@25fps
- CVBS: PAL/NTSC
Day/Night Mode: Color
Wide Dynamic Range (WDR): ≥130 dB
Image Enhancement: BLC; HLC; Global; HLS
Privacy Mask: 4 programmable privacy masks
Noise Reduction: 3D DNR/2D DNR
White Balance: Auto/Manual
Event
Motion Detection 4: programmable motion areas
General
Power: 12 VDC ± 25%, max. 5.7 W
Material: Metal
Dimension: 194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
Weight: Approx. 515 g (1.13 lb.)
Operating Condition -40 °C to 50 °C (-40 °F to 122 °F), humidity 90% or less (non-condensing)
Communication: HIKVISION-C
Language: English
