HIK-VISION DS-2CE12DF0T-F CAMERA

Camera

• Image Sensor: 2 MP CMOS
• Max. Resolution: 1920 (H) × 1080 (V)
• Min. Illumination: 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
• Shutter Time: PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
• Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 180°, Rotation: 0° to 360°
• Signal System: PAL/NTSC
• Light Alarm: Solid Light Alarm (White Light)

Lens

• Lens Type: 2.8 mm, 3.6 mm, 6 mm fixed focal lens
• Focal Length & FOV: 2.8 mm, horizontal FOV: 98°, vertical FOV: 51°, diagonal FOV: 115° / 3.6 mm, horizontal FOV: 76°, vertical FOV: 41°, diagonal FOV: 90° / 6 mm, horizontal FOV: 50°, vertical FOV: 27°, diagonal FOV: 58°
• Lens Mount: M12

Illuminator

• Supplement Light Type: White Light
• Supplement Light Range: Up to 40 m
• Smart Supplement Light: Yes


• Image Parameters Switch: STD/HIGH-SAT/HIGHLIGHT
• Image Settings: Brightness, Mirror, Sharpness, Anti-Banding, AGC
• Frame Rate: TVI: 1080p@25fps/30fps / CVI: 1080p@25fps/30fps / AHD: 1080p@25fps/30fps / CVBS: PAL/NTSC
• Day/Night Mode: Color
• Wide Dynamic Range (WDR): Digital WDR
• Image Enhancement: DWDR, BLC, HLC, Global
• Noise Reduction: 3D DNR/2D DNR
• White Balance: Auto/Manual

Interface

• Video Output: Switchable TVI/AHD/CVI/CVBS

General

• Material: Metal
• Dimension: 194.2 mm × 78 mm × 74.5 mm (7.65" × 3.07" × 2.93")
• Weight: Approx. 516 g (1.14 lb)
• Operating Condition: -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
• Communication: HIKVISION-C
• Language: English
• Power: 12 VDC ± 25%, Max. 4 W
