HDMI SPLITTER 8 PORT
- AVAILABILITY:
- SKU: 1461
- CATEGORY: PC ACCESSORIES,CCTV ACCESSORIES
Rs. 4,450.00Rs. 4,100.00
6 MONTH WARRANTY
- 8-PORT HDMI SPLITTER: Displays the same image with sound on 8 screens; Splits an HDMI video signal up to Ultra HD 4K 60Hz & 7.1 CH audio; 4:4:4 chroma subsampling support w/ bandwidth up to 18Gbps (HDMI 2.0b); HDR; HDCP 2.2 to HDCP 1.4 conversion
- EDID EMULATION: 1x8 HDMI splitter 4K automatically passes EDID between your video source and the display attached to port 1 ensuring native settings (such as resolution and refresh rate) are configured
- AUDIO SUPPORT: Audio output is supported on all ports simultaneously; Support for 7.1 surround sound audio including Dolby® True HD and DTS HD Master Audio
- LONG REACH: Reach up to 16.4ft (5m) with a passive HDMI cable; For longer distances, active HDMI cables or HDMI extenders are available (sold separately) to use with this HDMI splitter for eight TVs/projectors/monitors/displays
- EASY SETUP: No drivers required for this 1-input 8-output UHD HDMI 2.0 splitter box; Simply connect cables and power with the EDID switch set to Auto to get started; Wide screen monitor formats supported; HDMI/DVI compatible
Connector(s)
Connector A
1 - HDMI (19 pin)
Connector B
8 - HDMI (19 pin)
Environmental
Operating Temperature
0 ℃ to +45℃
Storage Temperature
-10℃ to 70℃
Humidity
10% to 85 % RH (no condensation)
Hardware
AV Input
HDMI
Ports
9
AV Output
HDMI
Cabling
HDMI
Audio
Yes
Industry Standards
HDMI 2.0
HDCP 2.2
Indicators
LED Indicators
1 - power LED
1 - input LED
8 - output LEDs
Packaging Information
Shipping (Package) Weight
1,2 kg [2,7 lb]
Package Quantity
1
Package Length
32,6 cm [12,8 in]
Package Width
26 cm [10,2 in]
Package Height
7,4 cm [2,9 in]
Performance
Maximum Digital Resolutions
3840x2160 (4K) @ 60Hz
Supported Resolutions
2560x1600
1920x1200
1920x1080 (1080p)
1280x720 (720p)
1920x1200
1920x1080 (1080p)
1280x720 (720p)
Wide Screen Supported
Yes
Audio Specifications
Physical Characteristics
Color
Black
Material
Steel
Product Length
25,8 cm [10,2 in]
Product Width
11 cm [4,3 in]
Product Height
2,6 cm [1,0 in]
Weight of Product
762 g [26,9 oz]
Power
Input Voltage
100 - 240 AC
Input Current
0.6A
Output Voltage
5 DC
Output Current
3 A
Center Tip Polarity
Positive
Plug Type
M
Power Consumption (In Watts)
15 W
Special Notes / Requirements
Note
This video splitter is not compatible with the AMD Radeon RX460 graphics card
Connect the HDMI display with the lowest resolution and refresh rate capability to output #1
If HDCP 1.4 display is connected to port #1 the whole system defaults to HDCP 1.4.
If HDCP 1.4 display is connected to port #1 the whole system defaults to HDCP 1.4.
What's in the Box
Included in Package
1 - HDMI splitter
1 - universal power adapter (NA/JP, UK, EU, ANZ)
1 - set of mounting brackets
