CP PLUS CP-VAC-D24L2-V3 2.4MP DOME CAMERA
- AVAILABILITY:
- SKU: 3608
- CATEGORY: CCTV CAMERS,ANALOG,OUTDOOR
- 2.4 MP HD Dome Camera - 20 Mtr. / 2.4 MP HQIS Pro Image Sensor
- 25/30fps@720P / Day/Night (ICR), AWB, AGC, BLC
- Plug-n-Play HD/SD Camera / 3.6mm Lens
- Equipped with fine IR LEDs for clearer night vision / IR Range of 20 Mtr.
-
Compatible with HDx, AHD, HDCVI, CVBS and HDTVI DVRs
2.4 MP HD Dome Camera - 20 Mtr. / 2.4 MP HQIS Pro Image Sensor
25/30fps@720P / Day/Night (ICR), AWB, AGC, BLC
Plug-n-Play HD/SD Camera / 3.6mm Lens
Equipped with fine IR LEDs for clearer night vision / IR Range of 20 Mtr.
Compatible with HDx, AHD, HDCVI, CVBS and HDTVI DVRs
Image Sensor1/4" 2.4 MP
HQIS Pro Image Sensor
Minimum Illumination Color(0.1Lux) , (0 Lux IR LED On)
Shutter Speed1/50s(1/60s)-1/100,000s(Auto/Fixed)
White Balance Auto Lens 3.6mm AGC Control Auto S/N Ratio≥39dB Back Light
Comp.Auto Resolution720P
Video Output1.0Vp-p
Composite Output (75O / BNC) ,
HD-AHD(720P)\ HD-TVI(720P)\ HD-CVI(720P)\ CVBS , CVI Default setting
Frame Rate 30fps(60Hz) ,25fps(50Hz) ICRsupport
Gamma Correction0.45 IRIR
Range of 20 Mtr.
No. of IR LEDs12pcs
Operating Temperature-20°C~+55°C
Humidity : 10% ~ 90% , =95% RH no dew
Power Source : DC12V(+/-10%)
Power Consumption : 0.4W(2.5W after SMD LED Powered on)
Dimension :99.85mm x 99.85mm x 69.80mm
Weight :0.15KG
