CABLE UTP HIKVISION CAT 6 DS-1LN6UZC0
- AVAILABILITY:
- SKU: 4212
- CATEGORY: NETWORK ACCESSORIES
- Stable electrical performance, compliant with ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801.
- Sheath with strong mechanical properties, and high tensile and compressive strength, reducing damage during the project.
- Excellent performance in the Fluke 90-meter permanent link test while working continuously at 50°C high temperature.
- Excellent performance in the Fluke 100-meter channel test while being continuously loaded with 57 V/1 A DC power (PoE).
- Solid-Bare Copper conductor with less resistance, and better electrical properties and transmission performance.
- Compliant with RoHS 2.0.
Price Per Meter - Rs.127/-
Stable electrical performance, compliant with ANSI/TIA-568.2-D, IEC61156, ISO/IEC11801.
Sheath with strong mechanical properties, and high tensile and compressive strength, reducing damage during the project.
Excellent performance in the Fluke 90-meter permanent link test while working continuously at 50°C high temperature.
Excellent performance in the Fluke 100-meter channel test while being continuously loaded with 57 V/1 A DC power (PoE).
Solid-Bare Copper conductor with less resistance, and better electrical properties and transmission performance.
Compliant with RoHS 2.0.
General
Category | Cat 6 |
Structure | U/UTP |
Fire Resistance | CPR Fca |
Usage Scenario | Indoor |
Conduct
Conductor Material | Solid-Bare Copper |
Conductor Diameter | 0.50 ± 0.01 mm 24AWG |
Insulation
Insulation Diameter | 0.88 ± 0.05 mm |
Sheath
Sheath Material | PVC |
Sheath Color | Grey |
Structure
Length | 305 ± 1.5 m |
Rip Cord | Yes |
Separator | Yes |
