AMD RYZEN 9 9950X PROCESSOR 100-100001277W0F
- AVAILABILITY:
- SKU: 0002347
- CATEGORY: PC ACCESSORIES,PROCESSORS
- Name :AMD Ryzen™ 9 9950X
- Family :Ryzen
- Series :Ryzen 9000 Series
- Form Factor :Desktops , Boxed Processor
3 YEARS WARRANTY
Name :AMD Ryzen™ 9 9950X
Family :Ryzen
Series :Ryzen 9000 Series
Form Factor :Desktops , Boxed Processor
General Specifications | ||
Name | AMD Ryzen™ 9 9950X | |
Family | Ryzen | |
Series | Ryzen 9000 Series | |
Form Factor | Desktops , Boxed Processor | |
Market Segment | Enthusiast Desktop | |
AMD PRO Technologies | NO | |
Consumer Use | Yes | |
Regional Availability | Global | |
Former Codename | Granite Ridge AM5 | |
Architecture | Zen 5 | |
# of CPU Cores | 16 | |
Multithreading (SMT) | Yes | |
of Threads | 32 | |
Max. Boost Clock | Up to 5.7 GHz | |
Base Clock | 4.3 GHz | |
L1 Cache | 1280 KB | |
L2 Cache | 16 MB | |
L3 Cache | 64 MB | |
Default TDP | 170W | |
Processor Technology | TSMC 4nm FinFET | |
for CPU Cores | ||
Processor Technology for I/O | TSMC 6nm FinFET | |
Die | ||
Package Die Count | 3 | |
Unlocked for Overclocking | Yes | |
AMD EXPO™ Memory | Yes | |
Overclocking Technology | ||
Precision Boost Overdrive | Yes | |
Curve Optimizer Voltage | Yes | |
Offsets | ||
AMD Ryzen™ Master Support | Yes | |
CPU Socket | AM5 | |
Supporting Chipsets | A620 , X670E , X670 , B650E , B650 , X870E , X870 | |
CPU Boost Technology | Precision Boost 2 | |
Instruction Set |
| |
Supported Extensions | AES , AMD-V , AVX , AVX2 , AVX512 , FMA3 , MMX-plus , SHA , | |
SSE , SSE2 , SSE3 , SSE4.1 , SSE4.2 , SSE4A , SSSE3 , x86-64 | ||
Thermal Solution (PIB) | Not Included | |
Recommended Cooler | Liquid cooler recommended for optimal performance | |
Max. Operating Temperature | 95°C | |
OS Support | Windows 11 - 64-Bit Edition , Windows 10 - 64-Bit Edition , | |
RHEL x86 64-Bit , Ubuntu x86 64-Bit | ||
Connectivity | ||
Native USB 3.2 Gen 2 | 4 | |
(10Gbps) Ports | ||
Native USB 2.0 (480Mbps) | 1 | |
Ports | ||
PCI Express® Version | PCIe® 5.0 | |
Native PCIe® Lanes | 28 , 24 | |
(Total/Usable) | ||
Additional Usable PCIe Lanes | X870E 8x Gen4 | |
from Motherboard | X870 4x Gen4 | |
X670E 12x Gen4 | ||
X670 12x Gen4 | ||
B650E 8x Gen4 | ||
B650 8x Gen4 | ||
NVMe Support | Boot , RAID0 , RAID1 , RAID5 , RAID10 | |
System Memory Type | DDR5 | |
Memory Channels | 2 | |
Max. Memory | 192 GB | |
System Memory Subtype | UDIMM | |
Max Memory Speed | 2x1R DDR5-5600 | |
ECC Support | Yes (Requires mobo support) | |
Graphics Model | AMD Radeon™ Graphics | |
Graphics Core Count | 2 | |
Graphics Frequency | 2200 MHz | |
USB Type-C® DisplayPort™ | Yes | |
Alternate Mode |
